PP Melt Blown Filter Cartridge With Orange Surface -JIELV JMBO Series PP Melt Blown  Filter Cartridge With Orange Surface -JIELV JMBO Series

Share this:

Product Series Introduction

Jielv JMBO Series Melt Blown filter cartridge is fusing and intertwined with polypropylene resin. 3-layer filtration structure, loose outside, and close inner side,  gradually changes deep filtration structure. Orange surface increases the surface area ensuring high filtration, high dirt holding capacity, and long service life.




• Thermal bond without using any binders and adhesives.

 100% pure PP components, suitable for wide chemical compatibility and no pollution to water/liquids.

 3-layer filtration structure ensure high dirt holding capacity, high efficiency, and long service life.

 Orange surface design extends surface filtration area.




•  Food and Beverage;

•  RO Pre-filtration;

• Drinking water;

•  Chemical

•  Microelectronics;

•  Plating

•  Pharmaceutics



OD: 63mm,115mm
I.D.: 28mm,30mm;
Length: 9.75", 9.87",10",20",30",40" ,50",60"
Media: PP
Support: PP
Cage/ core/End cap: PP
Gasket: Silicone, EPDM, NBR, Viton,etc.
Max.Operating temperature: 65°C
Max.Operating Pressure: 2.0bar @ 21°C,

Ordering Code

  Removal Rating      Diameter  Length End Cap  Seal Material Core
 JMBO  1=1μm A=OD63,ID28mm 975=9.75" Blank = DOE S=Silicone P=PP
 3=3μm B=OD63,ID30mm  987=9.87" E=226/FIN  E = EPDM Blank=without core
 5=5μm C=OD115,ID28mm 10=10" F=226/Flat N=NBR
10= 10μm   20=20" G=222/FIN  V = Viton
20= 20μm   30=30" H=222/Flat Blank=without
25= 25μm   40=40"
50= 50μm   50=50"
75= 75μm   60=60"
  100= 100μm
  150= 150μm
